Reviewing Changes — Changelog, Undo, Restore

Every edit you make in a workspace is tracked. Three features make this tracking visible and reversible.

Changelog

Undo / Redo​

Cross-cutting, session-level undo and redo is available from Edit → Undo / Redo, from the context menu of a workspace, or with Ctrl+Z / Ctrl+Y. The history belongs to the whole workspace, not to a single schema: one linear stream of changes across every schema in it, including the ones that span two schemas at once, such as copying a class from one into another.

What is tracked goes beyond class, attribute, association, enum entry, package, and ontology edits. Importing, deleting, and renaming a schema, the namespace table of the workspace, custom SHACL shapes, diagrams, and diagram layout are part of the same history. The layout a diagram is given the first time you open it is not: opening a diagram is not something to undo, and it usually leaves what you can redo untouched.

Because undo reaches the whole workspace, a step can take back something you are not looking at. RDFArchitect says what it undid and in which schema, and asks first when the step would make a whole schema or diagram disappear.

The backend keeps up to 256 changes per workspace by default (configurable) and folds older states into the state they started from as you keep editing.

Changelog view​

View → Changelog opens a dedicated page that lists the change history of the currently selected workspace: what was added, updated, or deleted, with an inline diff for each change. The left pane groups changes by class, the right pane shows the full triple-level detail of the selected change with additions in green and deletions in red, labelled with the schema each part of the change belongs to.

This is the view to use when reviewing what happened between two editing sessions, or when preparing a release note.

Restore a previous version​

From the changelog you can restore the workspace to any earlier point, which takes back every change made after it, in all of its schemas rather than only the one you have open.

A restore of the whole workspace steps back through the history, so the changes it takes back can be redone afterwards.

Restore a single schema​

In the changelog of a single schema, the restore dialog offers Restore only this schema. It puts back that schema's content, shapes and diagrams the way the chosen version left them and leaves the other schemas alone. Because it cannot step through the history without taking the other schemas along, it is recorded as a new change of its own: it can be undone like any other, but changes that were undone before it can no longer be redone.

A schema can only be restored on its own to a version from after it was created. For an older version — for example the state the workspace was loaded in, before the schema was imported — the dialog offers only the whole workspace.

If the workspace changes while the dialog is open, for example in another tab, the restore is refused and the changelog reloads, so that you can confirm again with what the restore would now do.
